Let's go HIGHTOWER

Santacruz Hightower

M L

MATERIAL Carbon C

DÄMPFER RockShox Super Deluxe Select+

GABEL FOX 36 Float Performance Elite, 150mm

BREMSSCHEIBEN Shimano XT - RT-86, Ice Tech, 203mm/180mm

KETTENBLATTGARNITUR Shimano XT M8100, 30t

170mm (S-L)
175mm (XL-XXL)

SCHALTVORRICHTUNG Shimano XT M8100, 12spd

SCHALTWERK Shimano XT M8100, 12spd

KASSETTE Shimano XT M8100, 12spd, 10-51t

SATTELSTÜTZE RockShox Reverb Stealth 31.6

REIFEN Maxxis

Maxxis Minion DHR2 29"x2.4" 3C EXO TR
Maxxis Minion DHR2 29"x2.4" 3C EXO TR

GEWICHT 14.76kg

Verfügbare Grössen

Grösse: cm | in

GRÖSSEN	S (Low/High)	M (Low/High)	L (Low/High)	XL (Low/High)	XXL (Low/High)
A-Reach	425/428mm	450/453mm	470/473mm	490/493mm	515/518mm
B-Stack	603/601mm	612/610mm	621/619mm	639/637mm	662/660mm
C-Head Tube Angle	65.2/65.5°	65.2/65.5°	65.2/65.5°	65.2/65.5°	65.2/65.5°
D-Seat Tube Length	380mm	405mm	430mm	460mm	500mm
E-Front Center	745mm	774mm	798mm	827mm	862mm
F-BB Height	340/344mm	340/344mm	340/344mm	340/344mm	340/344mm
G-BB Drop	33/29mm	33/29mm	33/29mm	33/29mm	33/29mm
H-Wheelbase	1179mm	1208mm	1232mm	1261mm	1296/1301mm
I-Chainstay Length	434mm	434mm	434mm	434mm	434mm
J-Head Tube Length	90mm	100mm	110mm	130mm	155mm
K-Top Tube Length	567mm	596mm	619mm	646mm	660mm
L-Seat Tube Angle	76.7/77.1°	76.7/77.1°	76.7/77.1°	76.7/77.1°	76.7/77.1°
M-Standover	699/704mm	713/718mm	713/717mm	713/718mm	704/709mm
